使用docker acme申请、续订泛域名证书，并自动重载docker nginx_Docker_教程

使用docker acme申请、续订泛域名证书，并自动重载docker nginx

admin

2025-01-03 0 阅读

本文最后更新于 2022年03月21日

2022.03.21更新 ACME ECC RSA双证书

本站在迁移服务器后，决定在新环境中把所有服务都使用docker部署。这不难，甚至可以说是很方便，因为之前除了NGINX外，基本所有服务都是通过docker部署的。为啥之前没有用docker nginx？因为一直用certbot，certbot太方便了。

借着这次迁移站点，正好研究一下docker acme

之前一直不知道acme怎么能够操作docker nginx，因为容器是互相隔离的，谁也看不见谁的进程，觉得可能需要写一个脚本，通过宿主机来定时重启NGINX容器，但是在偶然间，搜索到了一个issue，发现原来docker acme是可以操作docker nginx的。

Docker 下，a container to another container 的部署方式结果与配置不一致 https://github .com/acmesh-official/acme.sh/issues/2400

于是乎按照这位老哥的配置，简单修改了一下，便成功了。

快速部署docker acme nginx

这里推荐一下我基于官方docker nginx编译添加模块的NGINX，可以直接开启brotli压缩。

https://github.com/SuperNG6/docker-nginx

具体如何操作我写在了注释里，非常简单，唯一需要注意的一点就是，在还未生成证书之前，不要修改NGINX配置文件，以免NGINX不停报错重启。

这里推荐使用dns验证，可以不占用80端口

 version: '3.1'
services:
nginx:
image: superng6/nginx:debian-stable-1.18.0
container_name: docker_nginx
restart: unless-stopped
network_mode: host
labels:
- 'docker_nginx'
volumes:
- /usr/share/zoneinfo/Asia/Shanghai:/etc/localtime:ro
- /var/www/html:/var/www/html
- /root/nginx/nginx.conf:/etc/nginx/nginx.conf
- /root/nginx/conf.d:/etc/nginx/conf.d
- /root/nginx/ssl:/etc/nginx/ssl
- /root/nginx/logs:/var/log/nginx

acme:
image: neilpang/acme.sh
container_name: acme
restart: unless-stopped
environment:
DP_Id: '这里填dnspod id'
DP_Key: '这里填dnspod key'
DEPLOY_DOCKER_CONTAINER_LABEL: 'docker_nginx'
DEPLOY_DOCKER_CONTAINER_KEY_FILE: '/etc/nginx/ssl/all.sleele.com/sleele.com.key'
DEPLOY_DOCKER_CONTAINER_FULLCHAIN_FILE: '/etc/nginx/ssl/all.sleele.com/fullchain.cer'
DEPLOY_DOCKER_CONTAINER_RELOAD_CMD: 'nginx -s reload'
volumes:
- /usr/share/zoneinfo/Asia/Shanghai:/etc/localtime:ro
- /var/run/docker.sock:/var/run/docker.sock:ro
- /root/nginx/acme.sh:/acme.sh
- /root/nginx/ssl:/etc/nginx/ssl
command: daemon
# 首次运行先进入容器生成证书
# acme.sh --issue --dns dns_dp -d sleele.com -d *.sleele.com
# docker exec -i acme acme.sh --issue --dns dns_dp -d sleele.com -d *.sleele.com
# 然后部署证书到指定文件夹
# acme.sh --deploy -d sleele.com --deploy-hook docker
# docker exec -i acme acme.sh --deploy -d sleele.com --deploy-hook docker

2022.03.21更新 acme换用zero ssl 首次使用需注册邮箱

初撰本文时，acme还没有使用zero ssl，随着版本迭代，acme.sh换用了zero ssl，首次使用必须要注册邮箱才可以

docker exec -i acme-rsa acme.sh --register-account -m my@example.com

首次运行先生成泛域名证书，然后再部署证书

docker exec -i acme acme.sh --issue --dns dns_dp -d 你的域名.com -d *.你的域名.com

docker exec -i acme acme.sh --deploy -d 你的域名.com --deploy-hook docker

所有二级域名都可以使用这个证书，所以NGINX里每个站点的配置文件都指向这个证书就可以了

NGINX HTTPS CONF

这里给两个，一个反向代理，一个正向代理。

反向代理

 # generated 2021-03-27, Mozilla Guideline v5.6, nginx 1.18.0, OpenSSL 1.1.1d, intermediate configuration
# https://ssl-config.mozilla.org/#server=nginx&version=1.18.0&config=intermediate&openssl=1.1.1d&guideline=5.6
server {
listen 80;
listen [::]:80;
server_name 你到域名;
return 301 https://$host$request_uri;
}

server {
listen 443 ssl http2;
listen [::]:443 ssl http2;
server_name 你到域名;
location / {
proxy_pass http://你要反代的ip:端口;
proxy_redirect off;
# 保证获取到真实IP
proxy_set_header X-Real-IP $remote_addr;
# 真实端口号
proxy_set_header X-Real-Port $remote_port;
# X-Forwarded-For 是一个 HTTP 扩展头部。
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
# 在多级代理的情况下，记录每次代理之前的客户端真实ip
proxy_set_header HTTP_X_FORWARDED_FOR $remote_addr;
# 获取到真实协议
proxy_set_header X-Forwarded-Proto $scheme;
# 真实主机名
proxy_set_header Host $host;
# 设置变量
proxy_set_header X-NginX-Proxy true;
# 开启 brotli
proxy_set_header Accept-Encoding "";
}

# 日志
access_log /var/log/nginx/access.log;
error_log /var/log/nginx/error.log;
# 证书
ssl_certificate /etc/nginx/ssl/all.sleele.com/fullchain.cer;
ssl_certificate_key /etc/nginx/ssl/all.sleele.com/sleele.com.key;

# curl https://ssl-config.mozilla.org/ffdhe2048.txt > /path/to/dhparam
ssl_dhparam /etc/nginx/ssl/dhparam;

# HSTS (ngx_http_headers_module is required) (63072000 seconds)
add_header Strict-Transport-Security "max-age=63072000" always;

# OCSP stapling
ssl_stapling on;
ssl_stapling_verify on;

# verify chain of trust of OCSP response using Root CA and Intermediate certs
ssl_trusted_certificate  /etc/nginx/ssl/all.sleele.com/fullchain.cer;
# replace with the IP address of your resolver
resolver 223.5.5.5;
resolver_timeout 5s;
}

正向代理

 # generated 2021-03-27, Mozilla Guideline v5.6, nginx 1.18.0, OpenSSL 1.1.1d, intermediate configuration
# https://ssl-config.mozilla.org/#server=nginx&version=1.18.0&config=intermediate&openssl=1.1.1d&guideline=5.6
server {
listen 80;
listen [::]:80;
server_name tk.sleele.com;
return 301 https://$host$request_uri;
}

server {
listen 443 ssl http2;
listen [::]:443 ssl http2;
server_name tk.sleele.com;
location / {
root /var/www/html/aria2-trackers;
index index.html;
}

# 日志
access_log /var/log/nginx/tk-access.log;
error_log /var/log/nginx/tk-error.log;

# 证书
ssl_certificate /etc/nginx/ssl/all.sleele.com/fullchain.cer;
ssl_certificate_key /etc/nginx/ssl/all.sleele.com/sleele.com.key;

# curl https://ssl-config.mozilla.org/ffdhe2048.txt > /path/to/dhparam
ssl_dhparam /etc/nginx/ssl/dhparam;

# HSTS (ngx_http_headers_module is required) (63072000 seconds)
add_header Strict-Transport-Security "max-age=63072000" always;

# OCSP stapling
ssl_stapling on;
ssl_stapling_verify on;

# verify chain of trust of OCSP response using Root CA and Intermediate certs
ssl_trusted_certificate  /etc/nginx/ssl/all.sleele.com/fullchain.cer;
# replace with the IP address of your resolver
resolver 223.5.5.5;
resolver_timeout 5s;
}

nginx.conf


load_module /usr/local/nginx/modules/ngx_http_brotli_filter_module.so;
load_module /usr/local/nginx/modules/ngx_http_brotli_static_module.so;
load_module /usr/local/nginx/modules/ngx_http_cache_purge_module.so;

user www-data;
worker_processes auto;
pid /run/nginx.pid;
include /etc/nginx/modules-enabled/*.conf;

events {
worker_connections 768;
# multi_accept on;
}

http {

##
# Basic Settings
##

sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
# server_tokens off;

# server_names_hash_bucket_size 64;
# server_name_in_redirect off;

include /etc/nginx/mime.types;
default_type application/octet-stream;

##
# SSL Settings
##
ssl_session_cache   shared:SSL:50m; # speed up first time. 1m ~= 4000 connections
ssl_session_timeout 1d;
ssl_session_tickets off;
ssl_protocols TLSv1.1 TLSv1.2 TLSv1.3; # Dropping SSLv1, ref: POODLE
ssl_prefer_server_ciphers on;
ssl_ciphers         'TLS13-AES-256-GCM-SHA384:TLS13-CHACHA20-POLY1305-SHA256:TLS13-AES-128-GCM-SHA256:TLS13-AES-128-CCM-8-SHA256:TLS13-AES-128-CCM-SHA256:EECDH+CHACHA20:EECDH+CHACHA20-draft:EECDH+ECDSA+AES128:EECDH+aRSA+AES128:RSA+AES128:EECDH+ECDSA+AES256:EECDH+aRSA+AES256:RSA+AES256:EECDH+ECDSA+3DES:EECDH+aRSA+3DES:RSA+3DES:!MD5'; ssl_prefer_server_ciphers on;


ssl_buffer_size 4k;
##
